Using cutting-edge technology, SmartSolar maximizes the energy harvesting capability of a solar charge controller to intelligently achieve max charge in the shortest possible time.

Features

• Ultra Fast MPPT

  • The MPPT VE.Can SmartSolar charger connects to a PV array of 150 or 250 Volt Voc and will automatically detect and charge your 12, 24, or 48V battery bank with current ranging from 70 to 100A depending on the model.

    The charge settings are fully programmable and can even be set up for different battery chemistries, like lead-acid, lithium and others.

• Remote Monitoring and Control
  • The MPPT VE.Can SmartSolar charger can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, and historical data.


• Load Output
• Configure the voltage at which SmartSolar disconnects a load.


• Daisy Chain Additional Units

  • The VE.Can SmartSolar charger is equipped with CAN bus ports. This allows for communication with additional VE.Can SmartSolar chargers. The additional units are simply “daisy chained” to each other with a single RJ45 cable between the individual units.

    When connected to each other, all individual VE.Can SmartSolar chargers, will synchronise their charge stages. They can also send their data, via a single cable, to a GX monitoring device.

Additional Information

SKU: 1593101

Weight: 4.5 kg / 9.9 lbs.

Dimensions: 216 x 295 x 103 mm

Battery Voltage: 12/24/48V

Max VOC: 250V

Protection Category: IP43
